Hayward - W3S220T Pro Series 22" In Ground Pool Sand Filter with 1-1/2" Top Mount Multiport Valve

Item No. 340105 | Manufacturer SKU: W3S220T
Item No. 340105 | Manufacturer SKU: W3S220T
Hayward  W3S220T Pro Series 22 In Ground Pool Sand Filter with 1-1/2 Top Mount Multiport Valve
Hayward  W3S220T Pro Series 22 In Ground Pool Sand Filter with 1-1/2 Top Mount Multiport Valve
Hayward  W3S220T Pro Series 22 In Ground Pool Sand Filter with 1-1/2 Top Mount Multiport Valve
Hayward  W3S220T Pro Series 22 In Ground Pool Sand Filter with 1-1/2 Top Mount Multiport Valve Hayward  W3S220T Pro Series 22 In Ground Pool Sand Filter with 1-1/2 Top Mount Multiport Valve Hayward  W3S220T Pro Series 22 In Ground Pool Sand Filter with 1-1/2 Top Mount Multiport Valve
$699.00

Hayward W3S220T Pro Series 22" Sand Filter with 1-1/2" Top Mount Multiport Valve for In-Ground and Above Ground Pools. More Details

subscription order icon Membership Available

Hayward W3S220T Pro Series 22" Sand Filter with 1-1/2" Top Mount Multiport Valve for In-Ground and Above Ground Pools.
  • 1-1/2" VariFlo Valve included
  • Compatible with valves: SP0714T, SP071620T
  • In-ground pools of all types and sizes
  • In-ground spas (residential or commercial)
  • Water features (fish ponds, fountains, water gardens)
  • Requires 250 lbs of sand
  • Flange clamp design allows 360 degree rotation of valve to simplify plumbing
  • Integral top diffuser ensures even distribution of water over the top of the sand media bed. Full-size internal piping provides smooth, free-flowing performance
  • Unitized, corrosion-proof filter tank molded of rugged, colorfast polymeric material for dependable, all-weather performance
  • Large pressure sand/water drain for rapid winterizing or servicing
  • 6 position Hayward Vari-Flo control valve with easy-to-use lever-action handle lets you dial any of the valve/filter functions. Integral sight glass lets you see when backwash cycle is completed
  • Precision engineered umbrella-fold self cleaning laterals for balanced flow and backwashing, plus easy serviceability
  • Certified to NSF/ANSI/CAN 50

The Hayward W3S220T Pro Series 22" Sand Filter with 1-1/2" Top Mount Multiport Valve provides you with quality you can trust. The Hayward Pro Series high-rate sand filters incorporate the latest pool filter technology to ensure your in ground or above ground pool is operating at its very best. The Hayward Pro Series 22" Sand Filter includes all the laterals inside the tank, filter tank base, pressure gauge, and Top Mount 1-1/2" Multiport Valve. The Hayward W3S220T has a 22" tank requiring 250 lbs. of sand (not included) for operation. Molded of durable, corrosion-proof reinforced thermoplastic, they feature attractive, unitized tank construction for years of trouble-free operation with only minimal care. Pro Series sets a new standard for performance, value and dependability.

Note: Filter includes 1-1/2 inch Vari-Flo Valve.

Simple to Operate
Sand Filters capture dirt and debris in the tiny gaps between sand particles. As the space between the particles fills up, water pressure builds. Cleaning the filter is as easy as switching the water flow and backwashing the debris safely out of the pool and filter. Sand should be replaced every 5-8 years.
Low Maintenance
Save time and energy by using a Sand Filter! Sand filters require only basic backwashing maintenance to keep them running well, leaving you more time to sit back and enjoy your clean pool.

Product Type: Pool Filter
Installation Type: Residential
Filter Type: Sand
Filter Diameter: 22 in
Sand Capacity: 250 lbs
Pool Type: In Ground
Manufacturer: Hayward
GPM: 52 GPM
Filtration Area: 2.64 sq ft
Warranty: 3-Year

Three (3) Year Limited Warranty on Product, see Owner's Manual for a full description of warranty claims and coverage details.
