Pentair - EC-160340 Clean & Clear Plus 320 sq. ft. Cartridge Pool Filter - Limited Warranty
$1,329.00
Pentair Clean & Clear Plus Cartridge Filter CCP320 is a corrosion resistant 4-cartridge filtration system that combines top-end performance with low maintenance.
More Details
Membership Available
Frequently Bought Together
+
Total price: $1,593.99
Total price: $1,593.99
This item:
EC-160340 Clean & Clear Plus 320 sq. ft. Cartridge Pool Filter - Limited Warranty
$1,329.00Elite Replacement Filter Cartridge for Pentair Clean & Clear Plus 320 4-Pack
$264.99$389.99
Pentair Clean & Clear Plus Cartridge Filter CCP320 is a corrosion resistant 4-cartridge filtration system that combines top-end performance with low maintenance.
- Large filter area for increased dirt capacity
- 2" unions
- Four polyester filter cartridges
- 1-1/2" drain for winterization
- Internal air bleed
- Corrosion-resistant
- Filters down to 20 microns
- Durable injection-molded tank
- 100% drain clean-out port
- Certified to NSF/ANSI 50
- Replacement Filter Cartridges: Pleatco PCC80-PAK4
Pentair Clean & Clear Plus Cartridge Filter CCP320 is a 4-cartridge filtration system used on in-ground pools. Capable of filtering particles as small as 20 microns, the Pentair CCP320 pulls everything out that you can't see with the human eye. The Clean & Clear Plus filter's design provides maximum filter surface area to capture more dirt and solids, extending time between cleanings.
Pentair Clean & Clear Plus Design
Clean & Clear Plus Filters contain four polyester filter cartridges that hold enormous amounts of dirt yet are easy to clean. Constructed of fiberglass-reinforced polypropylene for strength, corrosion resistance, and stability, the Pentair CCP320 provides dependable service for years to come. The steel tension control clamp ring uses a 7/8" brass barrel nut to tighten and loosen for quick and easy access to internal parts, speeding up service routines. Along with an internal air bleed system, the Clean and Clear Plus prevents air buildup to keep the filter operating at peak performance. The air bleed system paired with the 1-1/2" drain ensures full draining during winterization. The Pentair Clean & Clear Plus 320 has a filter effect area of 320 sq. ft. with a maximum flow rate of 120 gallons per minute. The Pentair Clean and Clear Plus 320 requires 62" vertical clearance for installation.
The Pentair Clean & Clear Plus Cartridge Pool Filter delivers commercial-grade performance that keeps residential pools clean and sparkling, day in and day out.
Common Questions:
What are the dimensions of the Filter?- Tank Size: (DxH) 21.5" x 43"
- Approx. Weight: 65 lbs.
- The CCP320 will come with four brand new cartridges, two 2" unions for install, the tank body, steel clamp assembly and air relief valve.
- The CCP320 has a 120 GPM max flow rate.
- One year parts only warranty from the date of purchase. Please see the Pentair Warranty Card for more details.
How to Service a Clean & Clear Plus Cartridge Filter
Looking for Hayward Clean & Clear 320 sq. ft. Pool Filter Replacement Parts?
If you need a replacement part for your Hayward Clean & Clear Cartridge Pool Filter, click the following button to view the part list schematic and all available parts.
Click here for Hayward Clean & Clear 320 sq. ft Filter Replacement Parts
Worry less about maintaining your filter with a Cartridge Filter system. Filter cartridges can be easily removed for replacement and regular washing to prolong their effectiveness.
Cartridge Filters are a great option for those who want more energy efficient equipment, by reducing the pump pressure required for the filter operation. In addition to cost savings, lower pump pressure can help prolong the life of your pool pump!
Dirt particles as small as 10-15 microns get captured by Cartridge Pool Filters, making them perfect for pools that need an effective option for removing smaller debris and dust particles.
| Pool Type: | In Ground |
| Installation Type: | Residential |
| Product Type: | Pool Filter |
| Filter Type: | Cartridge |
| Eco-Friendly: | Yes |
| Manufacturer: | Pentair |
| Warranty: | 1-Year |
| Filtration Area: | 320 sq ft |
One (1) Year Limited Warranty on Product, see Owner's Manual for a full description of warranty claims and coverage details.
