Pentair Clean & Clear Plus Cartridge Filter CCP420 is a corrosion resistant 4-cartridge filtration system that combines top-end performance with low maintenance. More Details

subscription order icon Membership Available

Pentair Clean & Clear Plus Cartridge Filter CCP420 is a corrosion resistant 4-cartridge filtration system that combines top-end performance with low maintenance.
  • Large filter area for increased dirt capacity
  • 2" unions
  • Four polyester filter cartridges
  • 1-1/2" drain for winterization
  • Internal air bleed
  • Corrosion-resistant
  • Filters down to 20 microns
  • Durable injection-molded tank
  • 100% drain clean-out port
  • Certified to NSF/ANSI 50
  • Replacement Filter Cartridges: Pleatco PCC105-PAK4

Pentair Clean & Clear Plus Cartridge Filter CCP420 is a 4-cartridge filtration system used on in-ground pools. Capable of filtering particles as small as 20 microns, the Pentair CCP420 pulls everything out that you can't see with the human eye. The Clean & Clear Plus filter's design provides maximum filter surface area to capture more dirt and solids, extending time between cleanings.

Pentair Clean & Clear Plus Design

Clean & Clear Plus Filters contain four polyester filter cartridges that hold enormous amounts of dirt yet are easy to clean. Constructed of fiberglass-reinforced polypropylene for strength, corrosion resistance, and stability, the Pentair CCP420 provides dependable service for years to come. The steel tension control clamp ring uses a 7/8" brass barrel nut to tighten and loosen for quick and easy access to internal parts, speeding up service routines. Along with an internal air bleed system, the Clean and Clear Plus prevents air buildup to keep the filter operating at peak performance. The air bleed system paired with the 1-1/2" drain ensures full draining during winterization. The Pentair Clean & Clear Plus 420 has a filter effect area of 420 sq. ft. with a maximum flow rate of 150 gallons per minute. The Pentair Clean and Clear Plus 420 requires 68" vertical clearance for installation.

The Pentair Clean & Clear Plus Cartridge Pool Filter delivers commercial-grade performance that keeps residential pools clean and sparkling, day in and day out.

Common Questions:

What are the dimensions of the Filter?
  • Tank Size: (DxH) 21.5" x 49"
  • Approx. Weight: 74 lbs.
What comes with the CCP420?
  • The CCP420 will come with four brand new cartridges, two 2" unions for install, the tank body, steel clamp assembly and air relief valve.
What is the max flow rate for the CCP420?
  • The CCP420 has a 150 GPM max flow rate.
What warranty does the Pentair CCP420 carry?
  • One year parts only warranty from the date of purchase. Please see the Pentair Warranty Card for more details.

How to Service a Clean & Clear Plus Cartridge Filter

Looking for Pentair Clean & Clear Replacement Parts?

If you need a replacement part for your Pentair Clean & Clear Cartridge Pool Filter, click the following button to view the part list schematic and all available parts.

Click here for Pentair Clean & Clear Replacement Parts

Warranty: 1-Year
Product Type: Pool Filter
Filter Type: Cartridge
Filtration Area: 420 sq ft
Pool Type: In Ground
Manufacturer: Pentair
Product Dimensions: 22.5" Width x 44.8" Length x 22.3" Height
Product Weight: 74 lbs.
Warranty: 1 Year

One (1) Year Limited Warranty on Product, see Owner's Manual for a full description of warranty claims and coverage details.
