Hayward - W3HP21404T HeatPro 140K BTU, 230V, Titanium, Digital, Electric Pool Heat Pump
- For use with pool and spa applications
- 140,000 BTU
- Dimensions: 30-1/2"W x 34"D x 44"H
- 2" x 2-1/2" union fittings
- Dual thermostat
- Electronic temperature control
- Minimum/maximum flow rate: 30GPM/75GPM
- Quiet performance
- Note:Please refer to data sheet for exact shape and dimensions as this product image may not reflect the correct model. Each HeatPro Heat Pump has different dimensions based off of the BTU ratings.
- Important: Instructions for Accepting Your Freight Shipment
The Hayward HeatPro W3HP21404T 140,000 BTU Electric Heat Pump brings you quiet, efficient heating for your pool and spa. The Dual Electronic Thermostat provides continuous pool temperature display and is self diagnostic codes to monitor heat pump performance.
Designed with a safe, Non-ozone depleting R-410A refrigerant, the HeatPro includes an automatic defrost feature that senses cold temperatures and prevents freezing from occurring.
The Hayward HeatPro Heat Pump uses a 100% titanium heat exchanger for corrosion-free operation and the cabinet features A UV-resistant, injection molded shell resists rust and deterioration. These features help the heatPro withstand intense weather conditions and pool chemicals. A Thermostatic Expansion Valve (TXV) regulates refrigerant flow to maximize efficiency, as well as BTU output.
Using a 230V electrical connection, the heatpro Heat Pump is reliable and boasts higher heating efficiencies. Connecting to a dedicated 50 Amp breaker, the Hayward HeatPro is easy to install, utilizing its built-in inlet and outlet union connections. The HeatPro heat pumps are designed to be quiet and are eco-friendly, making them a dependable and safe heat pump for you and the environment.
The HeatPro heat pump is fully compatible with the Hayward automation systems. It is ETL-listed for safety, installs into 2" PVC piping and is designed with a minimum flow rate of 30 GPM and a maximum flow rate of 75 GPM, with a maximum working water pressure of 50 PSI. Unions are included.
Looking for Hayward W3HP21404T HeatPro Pool Heat Pump Replacement Parts?
If you need a replacement part for your Hayward W3HP21404T HeatPro, click the following button to view the part list schematic and all available parts.
|Pool Heat Pump
Three (3) Year Limited Warranty on Product, see Owner's Manual for a full description of warranty claims and coverage details.
