Raypak - 009217 Digital Natural Gas 266,000 BTU Pool Heater

Item No. 51811 | Manufacturer SKU: 009217
Item No. 51811 | Manufacturer SKU: 009217
Raypak  009217 Digital Natural Gas 266,000 BTU Pool Heater
Raypak  009217 Digital Natural Gas 266,000 BTU Pool Heater
Raypak  009217 Digital Natural Gas 266,000 BTU Pool Heater
$2,856.00

Raypak 009217 Digital Natural Gas Heater is built to last, the perfect solution for efficiency and versatility, providing optimal heating for your pool and spa. More Details

subscription order icon Membership Available

Raypak 009217 Digital Natural Gas Heater is built to last, the perfect solution for efficiency and versatility, providing optimal heating for your pool and spa.
  • LCD digital display control provides accurate temperature
  • High-wind and corrosion resistance
  • Modern compact design and construction
  • Copper heat exchanger
  • ProTek Shield module helps protect heat exchanger and extend life of heater
  • Electronic Ignition
  • 2" PVC connections
  • Ceramic fiber combustion chamber
  • For use in elevations from sea level to 2,000 feet
  • Part Number: 009217
  • Model Number: P-R266A-EN-C
  • Important: Instructions for Accepting Your Freight Shipment

The sleek and stylish Raypak Digital Natural Gas Heater features innovative technology designed to keep your pool or spa at the perfect temperature for your enjoyment. With a copper heat exchanger you can expect more heat transferred into your pool's water for less of the price. Flexible installation allows the Raypak Heater to be an addition to new or existing pool or spa systems.

Raypak Pool Heater Cutting Edge Features

Raypak's brilliant low-profile design, mixed with a corrosion resistant cabinet made from galvanized metal allows you to enjoy your heater year-round. The Raypak Digital Natural Gas Pool Heater is built tough with the ProTek Shield feature that protects the heat exchanger from outside forces and extends the life of the entire heater itself. The Raypak Heater comes with an easily removable stainless steel burner tray to help trap heat in and speed up ignition time. The Raypak Natural Gas Heater is fitted with copper finned-tubing and stainless-steel tube sheets helping to ensure rust-free operation which is important around pools and spas.

Pool & Spa Heating Made Easy

The Raypak Natural Gas Heater simplifies everything so you don't have to. The heater comes with a built-in electronic ignition, enabling the unit to turn the pilot light off and on when needed, conserving gas usage, and saving users money. Troubleshooting a Raypak Pool Heater is easier than ever with the on-board digital diagnostic controls. The display lets the owner and service professional know exactly what's always going on with the heater. The Raypak Natural Gas 266,000 BTU Heater comes with an intelligent digital display control system and a microprocessor-controlled thermostat to get the perfect temperature for your pool or spa every time. The heater also is compatible to be remote controlled from any two or three wired remote for added convenience. The soft operating gas valve ensures smooth turn on giving you no "Hard-light" to worry about.

The Raypak Digital Natural Gas Heater is engineered to last while offering simplicity and durability, ensuring optimal heating for your pool and spa.

Have a salt water chlorinated pool? Raypak has other heater models available, featuring a corrosion-resistant Cupro-Nickel heat exchanger. Raypak also offers an ASME rated pool and spa heater for commercial applications with bronze headers to meet commercial code requirements.

Common Questions:

What is the plumbing size?
  • The Raypak Natural Gas Heater is plumbed in 2" diameter piping.
What is the heat exchanger type?
  • The Raypak 009217 Digital Natural Gas Heater features a Copper Heat Exchanger.
What is the BTU of the Raypak 009217 Heater?
  • The Raypak 009217 Heater has a heat output of 266,000 BTU.




Instructions for accepting your freight shipment


Controlled Thermostat
The Raypak Digital gas heater comes with a microprocessor based thermostat control. This control allows you to set your swimming pool or spa temperature precisely at your favorite setting just by pressing an up or down temperature control button. The digital display gives you a constant read out of your swimming pool water temperature.
Self Diagnostic
Troubleshooting a gas heater has never been easier. The Raypak Digital has on-board diagnostic controls that let the user and the service professional know what is going on with the heater at all times. In the event that you would ever have a problem with the heater, the digital display will show where the problem is in the control circuit.
Remote Compatible
The Raypak Digital is compatible with most major swimming pool control and remote systems on the market today. Any two-wire or three-wire remote can connect to the Raypak Digital and be integrated into the pool control system of your choice.

Product Type: Pool Heater
Emission: Standard
Ignition: Electronic
Pool Type: In Ground
Fuel Type: Natural Gas
Heat Exchanger: Copper
Installation Type: Residential
Controls: Digital
Heat Output: 266,000 BTU
Elevation: 0 - 2,000 ft
Manufacturer: Raypak
Warranty: 1-Year
Model Number: P-R266A-EN-C

One (1) Year Limited Warranty on Product, see Owner's Manual for a full description of warranty claims and coverage details.
